Microscopes > Stereo microscope > Stereo zoom sets > Motic > SMZ-140 > Motic Stereo zoom microscope SMZ140-N2LED, bino, 10x/20, Al/Dl, LED 3W
Product no.: 76559

Stereo zoom microscope SMZ140-N2LED, bino, 10x/20, Al/Dl, LED 3W

$ 770.00 incl. VAT plus shipping costs
too expensive?
long-term
Product not available anymore + lead time

Product description

More about the series SMZ-140...

SMZ-140 / 143 In brief

  • The basic stereo microscope for teaching and university
  • Greenough system
  • Parfocal 4:1 zoom
  • Magnification 10x - 40x
  • LED or halogen lighting for reflected and transmitted light

Specifications SMZ-140-N2LED

Optical system: Greenough

Observation tube: Binocular head

Inclination: 45º inclined, 360º rotatable

Interpupillary distance: 54-76 mm

Diopter adjustment: On both eyepiece mounts, +/- 5 diopters

Eyepieces: Wide field WF10X/20mm

Objective concept: Zoom 1:4

Lenses: 1X - 4X

Working distance: 80 mm

Stand type: Stand column with transmitted light illumination

Head mount: For Ø25mm column and Ø74mm head, with incident light illumination

Focusing mechanism: coarse focus with smoothness adjustment

Focusing travel: 49 mm

Incident light illumination: LED 3W with intensity control

Transmitted light illumination: LED 3W with intensity control

Transformer: External

Power supply: 100-240V (CE)

Dimensions LxWxH: 237x170x335 mm

Base: 237x170mm

Stand column / arm: Height 210 mm / Ø25 mm

Net weight: 6.2 kg

Scope of delivery: Dust cover, black/white and matt glass table insert plate

Specifications

Optics


Magnification
40 (10x - 40x)
Eyepiece
10 (WF 10x/20mm)
Lighting
Incident light and transmitted light
Lamp type
LED
Power supply
100-240V, VDE plug (CE) mains adaptor
Optical system
Greenough
Zoom shot
yes

Capacity


Brightness control
yes

Mechanics


Type of build
binocular
Focusing
Coarse movement
Viewing posture (°)
45° angled eyepiece
Specimen stage
Specimen stage (black/white)
Working distance (mm)
80

Special features


Centering stage
-
Dust cover bag
yes
Filter holder
-
Wide-angle eyepiece
yes (10 x / 20)

General


Colour
grey/black
Series
SMZ-140
Width (mm)
170
Weight (g)
6.2
Height (mm)
335
Length (mm)
237

Field of application


Medicine
yes
Education
yes

Area of application


University
yes

Miscellaneous


supplier product number
1100200600813

Product safety

Manufacturer: Motic Deutschland GmbH, Christian-Kremp-Straße 11, 35578 Wetzlar, DE, http://www.moticeurope.com/
