MicroSpin 2 MP Digital Microscope
The intermediate-level MicroSpin is a 2MP desktop digital microscope with a six objectives wheel. A 2MP imaging sensor paired with upper and lower illumination for reflective and transparent illumination provides excellent resolution and illumination so you can capture high quality still images and video. A simple, non-adjustable stage with plastic clips holds slides in place for an optimized viewing experience.
The objective wheel rotates clockwise and counterclockwise, and locates in place at each position, making it easy to change powers. With six magnification powers from 100x up to 600x, this microscope is perfect for students and professionals alike.
Spezification
- Six objectives in vertically mounted objective wheel
- 100x, 200x, 300x, 400x, 500x, 600x magnification
- MicroSpin Capture Pro Software DVD/CD included
- Windows and Apple OS compatible
- Objectives (6)- (on wheel) 10x, 20x, 30x, 40x, 50x, 60x
- Stage Simple- non moveable stage with 10 mm stage hole and plastic clips
- Focus Course focus (moves objective wheel)
- Illuminators (1) Lower|(1) Upper|(2) Modes (Lower, Both)
- Still Image Resolution 2MP (1600 x 1200), 1MP (1280 x 720) , 800x600, 640x480, 320x240
- Effective Observation area 100x: 3.6 mm x 2.7 mm|200x: 1.8 mm x 1.4 mm|300x: 1.2 mm x 0.9 mm|400x: 0.9 mm x 0.7 mm|500x: 0.7 mm x 0.5 mm|600x: 0.6 mm x 0.45 mm
- PC Connection type USB 2.0
- Video Capture Resolution VGA, 20 fps, 640 x 480 or QVGA 320 x 240
- Software Languages Supported English, German, French, Spanish, Italian, Japanese, Chinese Simple, Chinese traditional
- Operating Systems supported Windows 8 / 7 / Vista / XP SP2, SP3; Mac OS X 10.4.8 - 10.10.x
- Dimensions 154 mm x 130 mm x 208 mm (6.06" x 5.12" x 8.18")
Included Accessories
- Prepared slide Blank slides
- Slide covers
- Pair of Tweezers
- Eye dropper
- CD/DVD ROM drive with software and Manual
- Quick Setup Guide
TetraView LCD Digital Microscope
The professional Celestron TetraView LCD Digital Microscope is a touch-screen LCD microscope with advanced features at a reasonable price. TetraView has four fully achromatic objectives, a fully mechanical stage, a 4.3" TFT full-colour touch screen, a 5MP CMOS sensor and a 2GB SD card to save your photos and videos to - taking high-resolution images and videos from slides has never been so easy. The LCD screen rotates 180 degrees so you can share your photos and videos with others, and for an even bigger audience, use the TV Out output to display on a TV or projector. With a range of magnifications from 40X to 400X (1600x with digital zoom), TetraView is ideal for viewing a range of cell samples on slides. The TetraView Microscope is ideal for the discerning professional or hobbyist and is an excellent tool for laboratories, schools, scientific research, and more.
- 40X to 400X magnification (up to 1600X with digital zoom)
- 4.3" LCD touch screen
- 5MP CMOS built-in digital camera
- 4 fully achromatic objectives: 4X, 10X, 20X, 40X
- adjustable LED bottom illumination
- 180° rotatable LCD screen
- fully mechanical stage
- coarse- and fine-focusing knobs
- filter wheel/diaphragm
- AV/TV output
- optional battery power (4 AA batteries)
- 2GB SD card included (SD card slot supports up to 32GB)
- universal power supply with multiple plugs for international use
- accessories included - 7 prepared slides, hard case, dust cover, touch-pen, USB cable, AV output cable
- Specifications
- imaging Sensor 5MP CMOS ½ 5", 10X magnification in lieu of eyepiece
- AC adapter universal input 100 to 240 volts, 50/60 Hz, 4 plugs multi-country
- USB port 2.0, 1.5m cable included
- magnification (low power) 40X
- magnification (high power) 400X
- continuous video (VGA), 20fps
- 4 AA batteries (user-supplied)
- revolving objective turret - 4-position with locking stop
- objective lenses - achromatic 4X, 10X, 20X and 40X
- condenser lens - +HEADER +0.65
- built-in bottom illumination - adjustable LED
- fully mechanical stage with metal clips, 88mm x 88mm (3.5" x 3.5")
- dimensions 178mm x 140mm x 330mm (7" x 5.5" x 13")
- weight 67oz / 1.9 kg
- high definition LCD touch screen, 480x272 pixels resolution, 109mm (4.3") with 4X digital zoom, with 180° rotation
